Stone Raymond Roller Mill System workflow

Date:2013-12-23   Views:1617
Stone Raymond Roller Mill System mainly contains small rock crusher, bucket elevator, hopper , vibrating feeder, Stone Raymond Roller Mill, Powder Bagging Machine, Electric control box, etc.
Stone Raymond Roller Mill System workflow is as follows:
1- First use one forklift to send the raw material into the big bunk before the small rock crusher.
2- The vibrating feeder under the big bunk sends the raw material into the small rock crusher evenly.
3- Small Rock Crusher crush the raw material into smaller size which is suitable for the raymond mill.
4- Bucket elevator or belt conveyor sends the crushed raw material into the hopper.
5- The vibrating feeder under the hopper sends the crushed raw materials into the grinding chamber of the raymond mill.
6- Under the function of the motor and main shaft, the rollers rotates in high speed, and grind the raw material together with the ring. There is one blower to blow the powder up to the powder classifier which is on the top of the raymond mill main frame. The fine powder which can pass through the powder classifier goes out as the product, the coarse powder falls down anf to be grinded by the roller and ring again.
7- The powder bagging machine is used to pack the powder into bag.
8- Electric control box is used to control all the motors in the Stone Raymond Roller Mill system.



Stone Raymond Roller Mill is mainly used to grind and process variety kinds of non-flammable and non-explosive materials with hardness less than 7 and humidity less than 6% in mining, construction, chemical industry, etc. Stone Raymond Roller Mill is ideal grinding machine to grind and process the materials such as limestone, gypsum, barite, carbonate calcium, marble, feldspar, dolomite, granite, kaolin, bentonite, bauxite, etc.The finished production fineness of stone raymond roller mill is: 30meshes~425meshes,If you have any questions about Stone Raymond Roller Mill, please do not hesitate to contact us.
